1.5KE36A Transient Voltage Suppressor Diode – DO-201AE

The 1.5KE36A Transient Voltage Suppressor Diode – DO-201AE is designed to protect sensitive electronics from high-energy voltage spikes generated by lightning strikes, inductive switching, and surge events. Its rugged DO-201AE package and fast clamping action ensure stable and reliable protection for industrial, automotive, and general-purpose power systems. Ideal for safeguarding power rails, data interfaces, and surge-prone circuits.

Features:

1. 1500 W peak pulse capability with 10/1000 s waveform
2. Glass passivated chip junction for enhanced stability
3. Fast response time for effective transient suppression
4. Excellent clamping performance with low incremental resistance
5. Halogen-free and RoHS compliant construction

Specifications:

• Reverse Stand-off Voltage (VR): 30.80 V
• Breakdown Voltage (VBR): 34.20 V to 37.80 V
• Test Current (IT): 1 mA
• Maximum Clamping Voltage (VC): 49.9 V
• Maximum Peak Pulse Current (Ipp): 30.5 A
• Maximum Reverse Leakage (IR): 5 A
• Peak Pulse Power Dissipation (PPPM): 1500 W
• Operating Junction Temperature (TJ): -65C to +175C
• Storage Temperature (TSTG): -65C to +175C

Package Includes:

1 1.5KE36A Transient Voltage Suppressor Diode – DO-201AE
