74HC32 – Quad 2-Input OR Gate IC
The 74HC Series’s 74HC32 IC is a 14 Pin Quad 2-Input OR Gate IC.The 74HC32 provides four independent 2-input OR gateswith standard push-pull outputs. The device is designed for operationwith a power supply range of 2.0V to 6.0V.Inputs include clamp diodes. Thisenables the use of current-limiting resistors to interface inputs to voltages in excess ofVCC.
Pinout:
Pinout of74HC32 IC
| Input Pins | 1, 2, 4, 5, 9, 10, 12, 13 |
| Inverting Output Pins | 3, 6, 8, 11 |
| Power Supply (VCC) | 14 |
| Ground (GND) | 7 |
Application:
- Toys
- Musical Instruments
- Medical Healthcare and Fitness
- Grid Infrastructure
- Electronic Point of Sale
- Test and Measurement
- Factory Automation and Control
- Building Automation
