Product Overview: The ACASOM Portable VIC-2 200MHz-300MHz FPV Drone Jammer is a high-performance, single-band jammer specifically designed to disrupt FPV drone signals. Equipped with a powerful 50W GaN anti-drone module and a 29.2V/5000mAh lithium battery, this device ensures an effective jamming range of up to 1-1.5 kilometers in radius, making it ideal for secure and controlled areas. Compact and lightweight at only 1.1kg, the VIC-2 is designed for convenient portability, with mounting options that allow it to be worn on the arm, waist, or chest.
Key Features:
- Frequency Customization: Operates in the 200MHz-300MHz range, with options to customize for various frequency bands, including 300-400M, 400-500M, 500-600M, and more, up to 5.8G.
- Adjustable Output Power: Available in multiple power configurations (10W, 20W, 30W, 40W, 50W, 60W) to accommodate different jamming distances. Lower power (10-30W) suits distances of 100-500 meters, while higher power (40-60W) extends coverage to 500-1500 meters.
- Built-In Battery for Extended Operation: The 29.2V 5000mAh lithium battery provides over 1 hour of continuous operation, ensuring reliability in critical situations.
- IP68 Waterproof and Durable Design: With an IP68 rating, the VIC-2 can withstand harsh weather conditions, making it suitable for outdoor and remote applications.
- Portable and Lightweight: At just 1.1kg and a compact size (177mm x 85mm x 43mm), the VIC-2 is easy to carry and deploy, complete with options to use in a Molle bag for hands-free operation.
- User-Friendly Controls: Features an LCD screen for battery capacity display and dedicated RF buttons for each band, allowing easy customization and operation in the field.
Specifications:
- Working Frequency: 200MHz-300MHz (customizable to other bands)
- Output Power: Up to 50W
- Action Distance: 1000-1500 meters (varies with real environment and power setting)
- Operating Temperature: -20C to +60C
- Battery Life: Approximately 1.5 hours on a single charge
- Battery Capacity: 29.2V / 5000mAh lithium battery
- Charging Adapter: 29.2V / 2A
- Waterproof Rating: IP68
- RF Port: N-F Connector
- Power Socket: IP68 Aviation Plug
- Shell Material: Aluminum
- Color: Military Green
- Weight: 1.1kg
- Dimensions: 177mm x 85mm x 43mm
Included Components:
- 1x ACASOM VIC-2 Portable Drone Jammer
- 1x 29.2V 2A Charging Adapter
- 1x Poly Bag for Storage
- 1x 3dBi Omnidirectional Antenna
Usage Instructions:
- Attach the antenna firmly before connecting the power adapter.
- For extended use, the device may get warm; it’s recommended to store it in the included poly bag.
- Ensure correct charging with the 29.2V/2A adapter.
For wholesale or custom frequency requirements, please contact support@rcdrone.top.
ACASOM Portable VIC-2 frequency jammer for FPV drones with easy-to-use buttons on front and back
ACASOM Portable VIC-2 Drone Jammer is a powerful frequency device that can block signals within a range of 200MHz to 300MHz, suitable for FPV racing and other applications.
Portable VIC-2 Drone Jammer, 200MHz-300MHz Fpv Frequency Blocking Device for Anti-Collision and Security
ACASOM Portable VIC-2 Drone Jammer operates at a frequency range of 200MHz to 300MHz, providing an effective solution for jamming Fpv drones.
Portable jammer device capable of disrupting drone signals within 200-300MHz frequency range.
ACASOM Portable VIC-2 Fpv Drone Jammer – Continuously working for up to 3 hours.
The ACASOM Portable VIC-2 is a drone jammer that operates within the frequency range of 200MHz to 300MHz, providing effective signal disruption and interference for secure operations.
ACASOM Portable VIC-2 Drone Jammer operating frequency range from 200MHz to 300MHz, with installation holes and screws (M4 and 1/8)
ACASOM Portable VIC-2 Drone Jammer, capable of blocking frequencies between 200MHz and 300MHz for enhanced FPV drone operation.
