Professional Heavy-Lift Agricultural & Cargo UAV 8kg Payload, 24kg Airframe, 1280mm, Carbon Fiber, 5km Video Link
This professional-grade 4-axis heavy-lift UAV is engineered for agricultural spraying, cargo transport, and industrial delivery applications. Built on a carbon fiber frame with a 1280mm symmetrical motor wheelbase and 23-inch blades powered by the X6 power system, it delivers a maximum payload capacity of 8kg with a 20-minute hover time under no load. The foldable design reduces the footprint to 660660500mm for transport and storage, while the 14801480500mm unfolded span provides the stability needed for heavy-lift operations. A biaxial camera gimbal with 1080p FHD imaging and 5km video transmission link rounds out the professional feature set. Suitable for expert operators in agricultural, logistics, and industrial UAV applications.
Key Features
- 8kg Maximum Payload – Heavy-lift capacity for agricultural and cargo missions
- 1280mm Wheelbase – Large platform for stability under load
- 23-Inch Blades / X6 Power System – High-efficiency propulsion for heavy-lift
- Carbon Fiber Frame – Lightweight and rigid construction
- Foldable Design – 660660500mm folded for transport
- 20-Minute Hover Time – No-load endurance
- 5km Image Transmission – Long-range video link
- 1080p FHD Camera – High-definition aerial imaging
- Biaxial Camera Gimbal – Stabilized 2-axis camera mount
- 10m/s Wind Resistance – Stable operation in challenging conditions
- 30 Maximum Pitch Angle – Controlled, stable flight envelope
Perfect For
- Agricultural spraying and crop monitoring
- Cargo transport and last-mile delivery
- Industrial inspection and survey missions
- Professional UAV operators requiring heavy-lift capability
- Research and development platforms
Technical Specifications
- Configuration: 4-axis quadcopter
- Symmetrical Motor Wheelbase: 1280mm
- Unfolded Size (incl. props): 14801480500mm
- Folded Size: 660660500mm
- Aircraft Net Weight: 24kg
- Maximum Takeoff Weight: 20kg
- Maximum Payload: 8kg
- Blade Size: 23 inches
- Power System: X6
- Maximum Ascent Speed: 8m/s
- Maximum Descent Speed: 6m/s
- Maximum Flying Speed: 10m/s
- Maximum Wind Speed: 10m/s
- Maximum Pitch Angle: 30
- Hover Time (no load): 20 minutes
- Camera: 1080p FHD
- Camera Gimbal: Biaxial (2-axis)
- Image Transmission Distance: 5km
- Frame Material: Carbon fiber
- Color: Black
- Shipping Size: 740740600mm
Important Notes
- Expert operator skill level required not suitable for beginners
- Compliance with local UAV regulations and airspace rules is the operators responsibility
- Agricultural and commercial UAV operations may require licensing in your region
- Battery not included contact us for compatible battery recommendations
- Technical guidance, installation instructions (video & PDF) available upon request
