Specifications
| Standard Equipment | |||
| Kit | 470LT Super Combo Torque Tube | 470LM Super Combo Belt | 470LP Super Combo Belt |
| Model | RH47E09X | RH47E01X | RH47E02X |
| Main Blades | Align 380mm Carbon Fiber Main Blades | Align 380mm Carbon Fiber Main Blades | Align 380mm Carbon Fiber Main Blades |
| Tail Blades | Align 69mm Tail Blades | Align 69mm Tail Blades | Align 69mm Tail Blades |
| Electronics Included | |||
| ESC | Align RCE-BL50X 50A Brushless ESC | Align RCE-BL50X 50A Brushless ESC | Align RCE-BL50X 50A Brushless ESC |
| ESC Programing | Transmitter Throttle Stick | Transmitter Throttle Stick | Transmitter Throttle Stick |
| Motor | 470MX Brushless Motor (1800KV/2818) | Align 470MX Brushless Motor (1800KV/2818) | Align 470MX Brushless Motor (1800KV/2818) |
| Cyclic Servo | Align DS450M Digital Servo x 3 | Align DS450M Digital Servo x 3 | Align DS450 Digital Servo X 3 |
| Tail Servo | Align DS455M Digital Servo | Align DS455M Digital Servo | Align DS455 Digital Servo |
| Servo Gears | Metal | Metal | Metal |
| Servo Case | All Metal | All Metal | Metal and Composite Material |
| Flybarless System | Microbeast Plus by Beastx | Microbeast Plus by Beastx | Microbeast Plus by Beastx |
| Flybarless Programming | Lights & Dials, or Studiox APP using Optional USB or Bluetooth Device | Lights & Dials, or Studiox APP using Optional USB or Bluetooth Device | Lights & Dials, or Studiox APP using Optional USB or Bluetooth Device |
| Stabilization Level Mode | Optional Update | Optional Upgrade | Optional Update |
| Rescue Mode | Optional Update | Optional Upgrade | Optional Update |
| Receiver Supported | DSM2/DSMX/DMSS Satellite, Futaba S.Bus, SRXL, JR XBUS, SUMD, M-Link, BEASTX SRXL, JETI UDI, SPPM, Standard Receiver | DSM2/DSMX/DMSS Satellite, Futaba S.Bus, SRXL, JR XBUS, SUMD, M-Link, BEASTX SRXL, JETI UDI, SPPM, Standard Receiver | DSM2/DSMX/DMSS Satellite, Futaba S.Bus, SRXL, JR XBUS, SUMD, M-Link, BEASTX SRXL, JETI UDI, SPPM, Standard Receiver |
| Specification | |||
| Assembly Required | |||
| Length | 755mm – 29.72in | 755mm – 29.72in | 755mm – 29.72in |
| Height | 210mm – 8.27in | 210mm – 8.27in | 210mm – 8.27in |
| Width | 108mm – 4.25in | 108mm – 4.25in | 108mm – 4.25in |
| Main Blade Length | 380mm – 18.50in | 380mm – 18.50in | 380mm – 18.50in |
| Main Rotor Diameter | 850mm – 33.46in | 850mm – 33.46in | 850mm – 33.46in |
| Tail Blade Length | 69mm – 2.72in | 69mm – 2.72in | 69mm – 2.72in |
| Tail Rotor Diameter | 181mm – 7.13in | 181mm – 7.13in | 181mm – 7.13in |
| Motor Pinion Gear | 11T | 11T | 11T |
| Main Drive Gear | 121T | 121T | 121T |
| Autorotation Driver Gear | 104T | ||
| Tail Drive Gear | 28T | 15T | 15T |
| Tail Drive System | Torque Tube | Belt | Belt |
| Drive Gear Ratio | 11:1:3.71 | 11:1:3.73 | 11:1:3.73 |
| Max RPM (approx.) | 3298 rpm | 3298 rpm | 3298 rpm |
| Weight (Without Battery) | 871g – 3072in | 860g – 33.86oz | 840g – 29.63oz |
| Battery Size | 6S Li-Po 1400 ~ 1850mAh | 6S Li-Po 1400 ~ 1850mAh | 6S Li-Po 1400 ~ 1850mAh |
| Main Drive Pulley | 56T | 56T |
Details
The Dominator Frex 3D Kom features a new 470mm painted canopy with aerodynamic design, durable fiber lightweight material providing best protection. The clean-cut outft makes overall body shape more balanced and stylish.
The Dominator Frex-47 has a 69mm tail blade, which are longer in length and offer superior holding performance even during demanding flight. The 380mm main blades effectively improve flying stability and power performance.
Alicn Dominator 470L main rotor holder ensures stable and controlled flight. Suitable for various flying conditions, this brand new V2 holder offers precise control and stability for pilots.
The Dominator FrexyTolt New Swashplate High Stability & Zero Slop delivers precise and accurate control with the 470MX Brushless Motor (1800KV). The motor features high efficiency, superior power, excellent torque, low current draw, and low operating temperature. It maintains consistent torque and head speed through continuous 30 maneuvers.
The Dominator TreXto Lt 3 CNC metal shapely reinforcement plate and brace assembly provides increased torsional strength for extreme 30 maneuverability. The 1.2mm 3K carbon fiber main frame features a proprietary composite material integration technology, creating a rigid and aesthetically pleasing structure.
RCE-BL SOX SOA Brushless ESC provides continuous current up to 65A with surge current support. It features a high-voltage BEC output of 8A, compatible with high-voltage servos. The quick-release buckle design simplifies battery insertion and removal while providing protection. The latching battery tray uses an integrated mounting rail for easy installation. This brushless ESC supports up to 6S 1800mAh batteries.
DOMINATOR FReXAtolt Age DSASOM HV DS4SSM HV Digital Servo. Stall Torque: -0 kg-cm, 2.2 kg-cm (6-8). Rating Voltage: DC 6.0-8.4V. Temperature Range: -20C to +60C. This product supports up to 8 channels for superior responsiveness, extreme torque, and improved performance.
The N3 Dominator FREX Progressive Lightweight Landing Skid is designed to improve aerodynamics and crashworthiness with a tilted angle of 5 degrees.
The Dominator IA Frex Stolt upgrade offers efficient torque tube drive, highly reducing gear abrasion and increasing power output for more direct and precise flight performance. This intense torque tube allows for reduced abrasion and extended gear lifetime value in extreme flight dynamics.
Newly designed vertical servo mount improves center of gravity and increases responsiveness in aerial applications.
The Dominator Trex Tolt Impact Resistance Vertical Stabilizer is designed with proprietary material integration technology, creating a unique look and improving its stiffness.
The Dominator FrexxToLt 470 Tail Boom features a wider tail boom design that improves torsional strength. The carbon fiber tail control rod assembly is practical and enhances helicopter tail control.
DOMINATOR FREXAToLt introduces a brand new tail rotor holder with thrust bearings, enhancing durability and performance. This innovative design improves accuracy and efficiency when using 69mm tall blades, perfect for ALICN ALIGN.
The Dominator Frexy Zolt Tail Control Unit features a newly designed dual-point supported tail control, delivering slope-free performance and improved rudder resolution for precision control.
New 470 canopy features in aerodynamic design with durable fiber lightweight material providing the best protection in flight. The new canopy, its enlarge clean-cut outfit makes the overall body shape more balance and stylish.
Extended 380mm main blades effectively improve the flying stability and power performance. The new engineered airfoil design effectively reduces turbulence at the end of the main blades,this saves power consumption during extreme 3D flight. New 69 size tail blades are longer in length and offer superior tail holding performance, even during demanding 3D flight.
Brand new 470 V2 Main Rotor Holder allow to provide the best stability and precise control no matter you are flying in static flight or 3D dynamic flight.
Brand New 470EFL Main Rotor Head provides superior flight stability and offers a lower CG design to reduce flying resistance while providing a more rigid and fast rotor head response. Brand New 470 Main Shaft and Feathering Shaft: Main Shaft outer dimension increased from 5mm to 6mm, while the Feathering Shaft outer dimension increased from 4mm to 5mm,effectively strengthening the Main and Feathering Shaft while improving durability.
New 470MX motor features; high efficiency, superior power, excellent torque, low current draw, and a low operating temperature. The 470MX is capable of maintaining consistent torque and head speed through continuous 3D maneuvers. 470MX motor is designed for 3D flight.
Brand new CNC metal reinforcement plate and brace compare with frame mounting bolt effectively increase the torsional stength of main frame, under extreme 3D maneuver, you can strongly feel its solid reinforcement from its structure.
Carbon fiber side frame plates are manufactured using a proprietary composite material integration technology which integrates the battery mounting rails into the frame. This unique use of open spaces within the frame creates a rigid frame and is aesthetically pleasing.
An additional 3rd main shaft bearing block increases the strength of the main frame while improving 3D flight.
Brand new latching battery tray which utilizes integrated mounting rails inside the frames to simplify insertion / removal of battery while providing protection for the battery.
Specially designed for T-REX 470 providing higher currency output and support for high voltage servos with an internal BEC output from 5V to 8.4V which can be set up based on servo specification.
DS350M HV Cyclic and DS455M HV Rudder servos support up to 8.4V for superior responsiveness, extreme torque, and improved performance.
Highly reduce gear abrasion and increase power output gives more direct and precise flight performance and extraordinary tail performance. The new high intense Torque Tube allow to reduce gear abrasion and extend the gear lifetime value in extreme flight dynamics.
Landing skid is tilted 5 degrees forward to improve crashworthiness.
Newly designed vertical tail servo mount to improve CG while increasing the responsiveness of 3D flight.
A wider Tail Boom to improves the torsional strength. Carbon Fiber Tail Control Rod is practical and improves the helicopters tail control.
Designed using a proprietary material integration technology which creates a unique look and improves the Vertical Stabilizer’s stiffness.
The newly designed dual point supported tail control assembly delivers slop free performance while improving rudder resolution and precision.
The new tail rotor holder design includes thrust bearings which increases durability, as well as significantly improving the accuracy and efficiency of the tail performance when using 69mm size Tail Blades.
