Overview
The Axisflying SEG TERK is an FPV video transmitter (VTX) module designed for analog FPV video transmission, specified for 4.9G-6G operation and up to 10W output power.
Key Features
- Axisflying SEG series VTX module (TERK)
- Analog FPV video transmitter (VTX)
- Frequency range: 4.9G-6G
- Rated output power: 10W (high power)
For compatibility questions or bulk inquiries, contact [email protected] or visit https://rcdrone.top/.
Specifications
| Brand | Axisflying |
| Series | SEG |
| Model/Variant | TERK |
| Signal Type | Analog |
| Frequency Range | 4.9G-6G |
| Output Power | 10W |
| Category | FPV video transmitter (VTX) module |
Applications
- Analog FPV video transmission setups
- FPV aircraft and drone builds requiring a high-power VTX module
Details
Axisflying TERK analog FPV VTX module features a compact metal case with integrated cooling fan and bottom SMA antenna connector.
The Axisflying analog FPV VTX lists up to 10W power with a 728V input range, CNC aluminum housing, a built-in micro fan, IRC Tramp control, and 80 frequency points.
Axisflying SEG 10W analog FPV VTX module measures 60.5 x 39 x 25 mm and includes labeled pads for VIDEO, 5V, RX/TX, and DC IN.
The 10W SEG analog VTX lists 728V input, 80 channels, 49006000MHz operation, and 60.53925mm dimensions.
Two onboard buttons (P and M) let you cycle band, channel, and power settings using the built-in digital display.
The SEG 10W analog VTX wiring includes DC IN (+7V to +28V), GND, RX serial control, 5V output, Video IN (1Vp-p @ 75), and an SMA antenna interface (4.96.0G).
The module includes an antenna, a 2P power cable, and a 4P connection cable for wiring and setup.
