BETAFPV Cetus pro/Cetus X SPECIFICATIONS

Warning: no

Video Capture Resolution: 720P HD

Type: HELICOPTER

State of Assembly: Ready-to-Go

Remote Distance: 100m

Remote Control: Yes

Recommend Age: 12+y

Plugs Type: usb

Package Includes: Original Box,Camera,Batteries,USB Cable,Operating Instructions

Origin: Mainland China

Operator Skill Level: Beginner,Intermediate,Expert

Motor: Brushless Motor

Model Number: Cetus Pro/X BNF

Material: Carbon Fiber,Plastic

Indoor/Outdoor Use: Indoor-Outdoor

Flight Time: 3-5mins

Features: FPV Capable

Controller Mode: MODE2

Controller Battery: No included

Control Channels: 8 Channels

Charging Voltage: 3.7V

Cetus pro Battery: BT2.0 450mah 1S Battery (external)

Cetus Pro Propeller: 40mm 3-blade 1.5mm shaft hole

Cetus Pro Motor: 1102-18000KV Brushless motor

Cetus Pro Flight controller: Lite 1-2S Pro brushless FC

Cetus Pro Camera: C02 FPV Micro Camera

Certification: CE

Camera Mount Type: Fixed Camera Mount

Brand Name: BETAFPV

Aerial Photography: Yes

Cetus X BNF

Cetus X is a primary choice for beginners who want to get advanced flight skills. The 2S power makes it stands out, giving Cetus X stronger propulsion and faster speed to perform diverse freestyle tricks.Equipped with M04 400mW VTX and C04 FPV camera that is optimized for longer radio and video transmission. Two FC versions provide differentfunctions to pilots but all help pilots to the next level.

Bullet Point

• An excellent preference for beginners to get advancedlevel. Cetus X brushless Quadcopter is proud of its lightning speed with rapid startupdueto its stronger propulsion system.

• Build-in ExpressLRS 2.4G receiver that is the most popular radio link, low latency, and far controlling range are possible. Pilots can not only enjoy the flight indoors but also explore the scenery outdoors.

• The drone with Frsky receiver protocol version is also provided for customers who used to haveLiteRadio 2 SE radio transmitterinCetus Pro or Cetus RTF Kit.

• Featuring M04 400mW VTX, C04 FPV camera (based on Caddx Nano Ant Camera or Runcam Nano 4), and 2*BT2.0 450mAh 1S 30Cbattery for longer radio and video transmission and flight endurance, Cetus X brushless quadcopter allows beginners to gain more achievements in FPV flight.

• The Betaflight FC comes with the most popular firmware in the FPV community. Beginners are able to learn and understand more about FPV, which is anessentialway to get drone experience.

• The Cetus FC version offers an auxiliary flight function for pilots with three speed modes. It is easier and more suitable for initial pilots.

Specification

• Item:Cetus X Brushless Quadcopter

• Weight: 55g

• Wheelbase: 95mm

• FC:F4 1S 12A FC(Betaflight FC Version)/Cetus BL V3 Flight Controller(Cetus FC Version)

• Motors:1103 11000KVMotor

• Props:Gemfan 2020 4-Blades Props

• Camera: C04 FPV Camera (Caddx Nano Ant Camera/Runcam Nano 4)

• Camera Adjustable Angle: 0-40

• Frame:Cetus X Brushless Whoop Frame

• Receiver Protocol: ELRS 2.4G (Betaflight FC Version only)/Frsky D8

• VTX: M04 25-400mW VTX (Betaflight FC Version)/Cetus 25-350mW VTX V2 (Cetus FC Version)

• Battery: 2*BT2.0 450mAh 1S 30C Battery

• Flight time: 5 mins

ExpressLRS 2.4G or Frsky D8

Equipped with F4 1-2S 12A flight controller, Cetus X brushless quadcopter supports ELRS 2.4G or Frsky D8 RX protocol. Both RX versions support the Betaflight configurator and have great performance in maneuverability, power, and flight time. Pilots who had Cetus Pro or Cetus RTF Kit can continue to use LiteRadio 2 SE radio transmitter to fly Cetus X Frsky D8 version.

Cetus FC or Betaflight FC

Cetus X with the classical Cetus flight controller version is released. It supports the position hold function, which provides easier control to pilots. If select the Betaflight FC version, pilots are able to learn and understand the drone configuration. Both FC versions perform great in power and speed and have higher-grade flight modes for pilots to get advanced.

	CetusFC Version	BetaflightFC Version
Flight Controller	Cetus BL V3 Flight Controller	F4 1S 12A Flight Controller
Receiver Protocol	Frsky D8	ExpressLRS 2.4G/Frsky D8
Flight Mode	N/S/M/Turtle Mode	Angle/Horizon/Air/Turtle Mode
VTX	25-350mW	25-400mW
Position Hold	Support	Not Support
Configuration Software	BETAFPV Configurator	Betaflight Configurator

Auxiliary Flight Function

Built-in highly precise barometer to detect the height,the version with Cetus FC benefits from great stability due to itspositionhold mode, and auto-hovering, whichenables the drone to stay at the current height.This function also ensures an emergency landing of the dronewhenever loses control or is on low battery.Meanwhile, its stable flight allows you to catch the best footage with the FPV Goggles. It really does an immense amount of fun and ease of flight for all pilots.Recommend flying it with BETAFPV VR03 Goggles.

Note: The positionhold function is only available in N mode.

Improved Video Transmission

Cetus X Brushless Quadcoptercomes withM04 25-400mW VTXand C04 FPV camera. The VTX features a lightweight and adjustable output power for longer distance flying. Combining this VTX and the excellent radio link ExpressLRS 2.4G/Frsky D8, pilots can fly whoop drones longer to explore more possibilities and have fun. In addition, C04 FPV camera (based onCaddx Nano Ant Camera/Runcam Nano 4) shows better quality in FPV flight compared withC02 FPV camera.

PowerfulPropulsion System

Equipped with1103 11000KV Brushless MotorandGemfan 2020 4-blade props. 1103 motors are designed for2S quadcopters with incredible power, smooth and quiet operation,and light enough. Besides, Cetus X quadcopter adopts 2020 4-blade props, which are lighter and durable enough, offering pilots a high-efficiency flight experience.

Primary Choice for NextLevel

Cetus X Brushless Qaducopter Betaflight FC version supports configuring on Betaflight configurator. It is aprimary choice for beginners who start to learn drone configuring, which helps beginners to get advanced level. With the Betaflight configurator, you can calibrate accelerometer, custom OSD content, adjust the video transmitter and etc.

Note: Please DO NOT configure ESC or Motor settings on Betaflight configurator.

Betaflight Flight Controller

Cetus X brushless quadcopter is built-inF4 1S 12A FC board, supporting ELRS 2.4G, or default Frsky D8 protocol. The ELRS 2.4G version comes with betaflight 4.3.1 FC firmware so it supports ELRS V2.0. The Frsky version can be switched to the Futaba SFHSS protocol through the Betaflight configurator.The ESC on the new board powered by BB51 hardware comes with Bluejay48k ESC firmware, allowing1103 11000KV motorsto give full play to the efficiency of power. We update the gyro to BOSH BMI270 for better performance and stability since the new F4 1-2S 12A FC.

	Cetus X (ELRS 2.4G)	Cetus X (Frsky D8)
FC Inside	F4 1S 12A FC SPI ELRS 2.4G	F4 1S 12A FC SPI Frsky
Gyro	BMI270	BMI270
FCFirmware	BETAFPVF411SX1280	BETAFPVF411RX
ESCFirmware	C_X_30_48_ for Bluejay BB51 hardware	C_X_30_48_ for Bluejay BB51 hardware

For Cetus X ELRS 2.4G version, the Betaflight firmware 4.3.0 and up start to support BMI270 gyro. For Frsky D8 version,we recommend using BETAFPVF411RX 4.2.11 firmware and CLI dump file offered by BETAFPV.

The default flight controller firmware enablesbidirectional D-shot and is compatible with Bluejay ESC firmware. If you update the 4.3.0 and up firmware for ELRS 2.4G from the Betaflight official site, please flash the CLI dump file for Cetus X.

Package

• 1 *Cetus X Brushless Quadcopter

• 1 * BT2.0 Battery Charger and Voltage Tester

• 2 * BT2.0 450mAh 1S 30C Battery

• 1 * Phillips Screwdriver

• 1 * Prop Removal Tool

• 1 * Type-C Adapter

• 4* Gemfan 2020 4-Blades Props

Cetus Pro BNF

Bullet Point

• The auxiliary flight function is greatly reducing the threshold of operating. This is the lightest key to open the door to advanced FPV.

• Cetus Pro quadcopter comes with a brushless power system, it’s more powerful and maneuverable in flight. Pilots can achieve more FPV freestyle actions to train.

• With the self-protection of emergency landing when out of control or in low battery, to ensure a more safe flight.

• Made of PA12 material, the frame has an excellent impact resistance in drop & impact. Meanwhile, the 360 protection of the whoop frame ensures safe flights both indoors and outdoors.

Altitude Hold, Easy to Fly

The altitude hold function enables Auto-Hover. This quadcopter can stay at a current height when pilots’ hands are off the transmitter. Barometer/laser achieves accurate and stable positioning, which makes the quad hovering indoors very stable. The flight has never been so easy for a beginner!

The altitude hold function is only available in N mode.

Self-protection, No More Dangers

The quadcopter comes with an excellent self-protection function. It can make an emergency landing whenever loses control or is in low battery. It will also automatically disarm and drop on the ground once there is a strong collision with the object. Let’s say goodbye to loss and crash!
