The Bob46 is the best of both 4 and 6 inch. 2RAWs newest addition to its lineup in the 5inch category. Targeted at content creators who want a drone that has balanced well rounded performance. The BOB46 doesn’t compromise in any areas it allows for the creator to have maximum options to be used in almost every scenario.
Highlights
No props in view from 40-0 degrees in both FPV feed and Action camera feed.
Front facing and reversible Action camera mounting options.
Larger body length to allow for bigger batteries for more flight time.
Small size for easy transport for content creation in remote locations
2RAW tuned, flawless footage in all conditions
Encased body to protect electronics from dirt and debris when filming
Recommended Accessories:
Default Propeller: Nazgul F5 Tri-blade Prop
Optional Propeller: GEMFAN Hurricane MAX 51377 Prop (for Nazgul)
Freestyle: DOGCOM 6S 1550mAh 150C Ultra Series Battery
Cinematic: DOGCOM 6S 1850mAh 150C Battery
Long Range: DOGCOM 6S 2200mAh 150C Battery
Max. Range: DOGCOM 6S1P 5000mAh Li-Ion Battery
Charger: HOTA D6 Pro 650W 1-6S Dual Channel AC/DC Smart Charger
GoPro Mount: 2RAW Slim GoPro TPU Mount
Specifications
Product Name: BOB46 O4 6S HD BNF
FC: BLITZ Mini F722
ESC: BLITZ Mini E55 4-IN-1 ESC
Video Transmission: DJI O4 Air Unit Pro
Frame diagonal motor distance: 226mm
Motor: XING2 2207 1750KV motors
Prop: Nazgul F5 propellers
Weight: 4555g
Takeoff Weight: Approx.6975g (With 6S 1480mAh)
Dimensions (LWH): 181*135*44mm
Max Speed: 165 km/h
Maximum Takeoff Altitude: 7000 m
Max Hover Time: Approx. 12-13 mins (No Load with 6S 1480mAh)
Max Wind Speed Resistance: Level 7
Operating Temperature Range: -20 to 40 C
Antennas: Single Antenna
GNSS: GPS+SBAS+Galileo+QZSS+Glonass
Video Transmission
Product Name: DJI O4 Air Unit Pro
Image Sensor: 1/1.3-inch
Lens: FOV: 155
ISO: 100-25600
Video Resolution: 1080p/100fps H.265
Video Format: MP4, Max Video Bitrate: 130Mbps
Color Mode: Normal Mode/D-Log M
Stabilization: RockSteady 3.0+ ; Stabilization function off (When RockSteady is enabled, the shooting angle only supports standard.)
Live View Quality: 1080P@100fps
Operating Frequency: 5.170-5.250 GHz & 5.725-5.850 GHz
Transmitter Power (EIRP): 5.1GHz23dBm(CE)/5.8GHz33dBm(FCC)/14dBm(CE)/30dBm(SRRC))
Max Video Transmission Range: With DJI Goggles 3/DJI Goggles N3: 15 km (FCC), 8 km (CE), 8 km (SRRC)
Communication Bandwidth: Max 60 MHz
Antenna: Dual antennas
Built-in Storage: 4GB
Supported SD cards: microSD (up to 512GB)
Operating Temperature: -10 to 40 C
Weight: Air Unit (camera module included): Approx. 32 g
Dimensions: Transmission Module: 33.533.513 mm (LWH)
Packing List
1 x BOB46 O4 6S HD BNF
1 x Antenna
1 x Battery pads
2 x Prop (Pairs)
Compatibility
DJI Goggles 3 / DJI Goggles N3+ DJI FPV Remote Controller 3
DJI Goggles 2 / DJI Goggles Integra + DJI FPV remote control 2
(Or another Radio to match the RX in the Drone)
The flight control firmware needs to be configured to support the SBUS protocol so that the DJI FPV remote controller can be used.
