Bright Tangerine LeftField Mini DJI Kit (52.5-55.5mm)

Bright Tangerine LeftField Mini DJI Kit (52.5-55.5mm)

Get your RED rig ready for gimbal shooting with our LeftField Mini DJI Kit (52.5-55.5mm), which takes your RED V-RAPTOR to new heights. Featuring our unique lift-off system from ARRI standard dovetails and setting the camera to the correct height for DJI gimbals, this kit gives you everything you need to get started with shooting.

Quick-Release Convenience

Though the LeftField Mini is more compact than LeftField 3 Baseplates, it still features our popular Open UP system for quick-release convenience. This allows you to seamlessly attach the LeftField Mini Baseplate onto any standard ARRI dovetail in moments. When in place, use the lever on the side to transition between locked, sliding and unlocked on the dovetail.

Compact Clearance

With Riser heights, you have approximately 3mm of leeway-which gives our Riser Shim the potential for a broad range of compatibility. For cameras with an optical centre distance of 52mm-55mm, such as the RED V-RAPTOR and V-RAPTOR X, this Riser Shim is ideal for elevating it on your Baseplate.

Easy Installation

The Riser Shim mounts to your LeftField Mini’s central channel via four M4 screws, sitting snugly within the baseplate. The three marked screw threads on the corners are for the DJI Receiver: which is also installed with the same M4 screws and just a few turns of a 3mm Hex Key. From there, clip your Dovetail into place and get shooting.

Part of the LeftField System

The LeftField system of quick-release baseplates are the most convenient mounting option for professional filmmakers. Our patented Open UP system allows you to cleanly mount your camera rig to any ARRI standard dovetail in moments, and release it just as quickly.

Key Features:

Optimised for RED V-RAPTOR

DJI Gimbal Ready Height

52.5-55.5 mm Camera Clearance

Quick-Release Open UP System

ARRI Standard Dovetail Mount

0.3 cm Riser Adjustment

1.475 cm Added Dovetail Height

Easy DJI Receiver Installation

What’s in the Box:

Bright Tangerine LeftField Mini DJI Kit (52.5-55.5mm)

LeftField Mini 15mm LWS Baseplate

DJI RS Receiver for LeftField Mini

DJI Riser Shim (52.5-55.5mm)
