DJI Matrice 4TD (No Battery/Drone Only)

TheDJI Matrice 4TD is a rugged, all-weather drone designed exclusively for the DJI Dock 3, enabling autonomous 24/7 operations in the harshest conditions. Equipped with advanced thermal imaging, extended flight time, and AI-powered features, its built for infrastructure inspections, emergency response, and public safety.

Key Features

1. Thermal & Night Vision Mastery

   • 640512 IR Camera: Detect heat anomalies, track targets in total darkness, and measure temperatures with precision
   • UHR Mode: Boost resolution to 12801024 for ultra-detailed thermal analysis
   • NIR Auxiliary Light: Illuminate targets up to 100 meters for full-color night vision

2. Unmatched Flight Performance

   • 47-Minute Flight Time: Operate longer with a 37% endurance boost vs. predecessors
   • IP55 Protection: Dustproof and water-resistant for harsh environments

3. Intelligent Obstacle Avoidance

   • LiDAR + Radar: Detect 12mm wires at 15 m/s, ideal for power line inspections
   • Low-Light Sensing: Four fisheye lenses enhance obstacle detection in darkness

4. Precision Imaging & Mapping

   • 48MP Telephoto Camera: Capture license plates from 250 meters or inspect bridge defects with an 80 tilt
   • 5-Directional Mapping: Create detailed 3D models for infrastructure surveys

5. Seamless Dock 3 Integration

   • Vehicle-Mountable: Deploy from trucks for rapid emergency response
   • FlightHub 2 AI: Automate routes, analyze real-time data, and generate cloud models mid-flight

6. DJI Care Enterprise Plus

   • Unlimited Repairs: Coverage for accidents, water damage, and flyaways.
   • 24/7 Support: Priority access to technical experts and replacement services.

Why Choose This Bundle?

• Critical Applications: Power grid inspections, search-and-rescue, firefighting, and disaster monitoring.
• Future-Proof: Compatible with third-party payloads and dual-drone relay systems
• Compliance: AES-256 encryption and customizable data controls for sensitive operations

Ideal For:

• Energy companies managing remote infrastructure.
• Emergency teams requiring real-time thermal insights.
• Public safety agencies conducting nighttime surveillance.

Specifications

Aircraft Specs

Weight: 1850 g (includes battery, propellers, microSD card; excludes third – party payloads)

Max Takeoff Weight: 2090 g

Dimensions: 377.7462.2212.5 mm (LWH, without propellers)

Max Ascent Speed: 6 m/s (Normal Mode), 10 m/s (Sport Mode)

Max Descent Speed: 6 m/s (Normal Mode), 8 m/s (Sport Mode)

Max Horizontal Speed (at sea level, no wind):

Normal Mode (with Obstacle Sensing Enabled): 15 m/s (forward), 12 m/s (backward), 10 m/s (sideways)

Sport Mode: 21 m/s (forward), 19 m/s (backward), 15 m/s (sideways)

Max Wind Speed Resistance: 12 m/s (during operation and takeoff/landing)

Max Takeoff Altitude: 6500 m

Max Flight Time: 54 minutes (measured in controlled test environment)

Max Hovering Time: 47 minutes

Max Operating Radius: 10 km

Max Flight Distance: 43 km (measured at 16 m/s, 20 m above sea level, 100% – 0% battery)

Max Pitch Angle: 25 (Normal Mode), 30 (Sport Mode)

Max Angular Velocity: 200/s

Global Navigation Satellite System: GPS + BeiDou + Galileo + QZSS + GLONASS (GLONASS and QZSS supported when RTK module is enabled)

Hovering Accuracy Range (windless or breezy):

Vertical: 0.1 m (vision positioning), 0.5 m (GNSS positioning), 0.1 m (RTK positioning)

Horizontal: 0.3 m (vision positioning), 0.5 m (GNSS positioning), 0.1 m (RTK positioning)

Operating Temperature: -20C – 50C (-4F – 122F)

Ingress Protection Rating: IP55

Motor Model: 2611

Propeller Model: 1364F foldable low – noise anti – ice propellers

RTK Module: Integrated on the aircraft

Beacon: Integrated on the aircraft

In the Box

• Matrice 4TD Aircraft (flight battery purchased separately)1
  CW Low-Noise Anti-Ice Propellers 2
  CCW Low-Noise Anti-Ice Propellers2
  Screws and Washers1
