Downlink System vtSPECIFICATIONS

Brand Name: uuustore

Origin: Mainland China

Material: Metal

RC Parts & Accs: Transmitters

For Vehicle Type: Airplanes

Upgrade Parts/Accessories: Hydraulic Transmission Box

Remote Control Peripherals/Devices: Remote Controller

Tool Supplies: Assembled class

Technical parameters: Value 2

Model Number: LM-COFDM1W

Four-wheel Drive Attributes: Assemblage

5-10KM Long Range Lawmate 5G 1000mw HDMI Digital Vdeo Transmission Downlink System For Filming Movie Live

Product Name :High Definition Digital Transmitter

Product model :LM-TX-COFDM1W

Working frequency band :500 ~ 520MHz (300 ~ 900MHz can be customized)

5030,5090,5150,5210Mhz

Antenna interface:50 SMA female

Modulation mode:COFDM

Video bit rate:2 ~ 5MHz

Working bandwidth:6 / 8MHz about 200 ~ 350ms delay

Compressed format H.264

Image definition:1080P @ 60/50/30 (backward compatible)

Working voltage:DC 9 ~ 28 v

Audio and video input interface:HDMI high-definition interface, CVBS analog standard definition interface

Power consumption 10W @ standard power 1000mW

Transmission distance:Vdieo Receiver with 2dBi antenna up to 2~4km,Receiver 5.5dBi antenna to 5~10km

weight:90g(without antenna)

size:82.5*62*22mm

Product Name:High Definition Digital Receiver

Product Model:LM-RX-COFDM1W
Working frequency band:500 ~ 520MHz (300 ~ 900MHz can be customized)
Antenna interface:50 SMA female
Modulation method:COFDM
Receiver parameters
Receiver sensitivity:-98dBm
Working bandwidth:6 / 8MHz
Video rate : 2 ~ 5MHz
Compressed format:H.264
Operating voltage:DC 9 ~ 18V
Video output interface:HDMI
Machine power consumption 4W
Weight 120g (without antenna)
Product size 107 * 77 * 20mm
