| Specification | |||
| EAV3SERIES | XM6352EA-10 | XM6352EA-15 | XM6352EA-20 |
| SKU() | 51788 | 51868 | 51869 |
| KV(KV) | 560 | 380 | 280 |
| Weight(g)() | 515 | 511 | 508 |
| Dimensions(DL)[mm]() | 63.1×55 | ||
| Diameter of Shaft (mm)() | 8.0 | ||
| Spec.of Mounting Holes() | 4-M4,32/32 4-M4,44/44 | ||
| Input Connectors() | DB4 | ||
| Dimensions of Stator(mm)() | 5322 | ||
| Slots &Poles() | 12N14P | ||
| Ri(mOhm)() | 7.4 | 15.1 | 26.3 |
| lo@10V(A)() | 3.7 | 1.9 | 1.2 |
| No.of Cells(LiPo)() | 5..6 | 61..8 | 8 |
| Efficiency Current[A]() | 60.0 | 50.0 | 41.0 |
| Burst Current (15S)[A]() | 120 | 100 | 82 |
| Peak Power(15S)[W]() | 2880 | 2400 | 2624 |
| Peak Torque [N M]() | 2.56 | 3.14 | 3.50 |
| Recommended ESC() | SUMMIT 120 | SUMMIT 120 | SUMMIT 120 |
| Recommended Propeller() | 5S:15x6E,16x8E | 6S1:18x12E, | 8S:18x12E, |
| 6S1:14×6,15x8E2 | 19x12E,20x10E | 19x10E,20x10E | |
| Application() | 125E,.95-.1202-stroke.Up to .1404st |
| EA V3 SERIES | XM6352EA-24SE |
| SKU () | 52121 |
| KV(KV) | 240 |
| Weight(g)() | 510 |
| Dimensions(DL)[mm]() | 63.1×55 |
| Diameter of Shaft (mm)() | 8.0 |
| Spec.of Mounting Holes() | 4-M4,32/324-M4,44/44 |
| Input Connectors() | DB4 |
| Dimensions of Stator(mm)() | 5322 |
| Slots &Poles() | 12N14P |
| Ri(mOhm)() | 36 |
| lo@10V(A)() | 0.8 |
| No.of Cells(LiPo)() | 10..121 |
| Efficiency Current[A]() | 38.5 |
| Burst Current (15S)[A]() | 77 |
| Peak Power(15S)[W() | 3419 |
| Peak Torque [N M]() | 3.83 |
| Recommended ESC () | SUMMIT 100HV |
| Recommended Propeller()
Application() |
10S:18x12E,19x10E,20x10E 12S:17x8E,17x10E,18x10E 12SHVtypeforUAV |
