Overview
The Futaba HPS-CB500 is a high-performance standard-size surface servo designed for 1/10 and 1/8 scale RC cars. both on-road and off-road. Powered by a custom high-torque brushless motor. it delivers rapid actuation at 0.06 sec/60 and peak torque of 25.5 kgfcm at 7.4V. Fully programmable via S.Bus2 and compatible with SR mode for ultra-fast communication. this servo is built for elite competition use and precision controlwithout BEC requirements.
Key Features
-
Optimized for Competition RC Ideal for 1/10 and 1/8 scale electric/nitro cars.
-
High-Torque Brushless Motor Custom-built for rapid response and lasting durability.
-
S.Bus2 + SR Mode Support Seamless pairing with Futaba T7PX/7PXR/T10PX transmitters.
-
Advanced Programmability PC tuning available via CIU-2 or CIU-3 interface (sold separately).
-
Durable Geartrain Metal gears from 1st to final stage; reinforced plastic case structure.
-
No BEC Use Not compatible with BEC systems; operates directly from HV battery packs.
Specifications
| Parameter | Details |
|---|---|
| Model | HPS-CB500 |
| SKU | 01102351-3 |
| Speed @ 7.4V | 0.06 sec/60 |
| Torque @ 7.4V | 25.5 kgfcm / 354.1 ozfin |
| Dimensions (LWH) | 40.5 21 34.8 mm (1.59 0.83 1.37 in) |
| Weight | 57 g (2.01 oz) |
| Rated Voltage | DC 4.8V 7.4V |
| Operating Voltage | DC 4.8V 8.4V |
| Motor Type | High-power brushless |
| Gear Material | Full metal internal geartrain |
| Case Material | Plastic (upper/middle/bottom) |
| Cable Color | Black-grey |
| BEC Compatibility | Not supported |
| Application | RC cars smaller than 1/5 scale |
