High altitude cleaning system drone SF-90X-150

Dimensions (unfolded, excluding propellers): 2026 mm x 2190 mm x 910 mm (L x W x H)

Dimensions (folded, excluding propellers): 1200 mm x 1080 mm x 850 mm (L x W x H)

Wheelbase: 2160 mm

Maximum takeoff weight (including undercarriage): Approximately 80 kg

RTK/GNSS frequency band: 2.400-2.483 GHz

Maximum flight radius (unobstructed and uninterrupted): 15 km

Maximum wind speed: 6 m/s

Maximum pitch angle: 15

Maximum horizontal flight speed: 15 m/s

Maximum altitude: 6000 m

Maximum flight time: Fully loaded: 20 minutes; unloaded: 40 minutes

Recommended operating temperature: 0C to 40C

Obstacle avoidance and range lock system

Obstacle avoidance: Millimeter-wave radar front-end obstacle avoidance

Obstacle avoidance range: 0.2m-30m
