The iFlight XING2 2207 and 2306 Brushless FPV Motors are designed to deliver exceptional performance for a variety of RC models, including airplanes and helicopters. Whether you’re a seasoned pilot or a hobbyist, these motors are engineered to enhance your flying experience with their robust build and advanced features.
Key Features:
5mm Titanium Alloy Shaft: The strongest prop shaft ever used in our motors, providing superior strength and durability under extreme conditions.
Crash-Resistant 7075 Aluminum Bell: The bell is constructed from high-grade 7075 aluminum, ensuring resistance to crashes and long-term durability.
Smooth and Long-Lasting NSK Bearings: Equipped with NSK 9x4x4 bearings, these motors offer smooth operation and extended service life.
Center Slotted N52H Curved Arc Magnets: These magnets drastically reduce motor response time, improving the overall flight control and precision of your RC model.
XING O-Ring Bearing Gap Protection: The O-ring system absorbs impact and vibrations, maintaining smooth and quiet performance even after crashes.
Motor Wires Protector: Protects the motor wires from damage, ensuring reliable operation.
Dynamically Balanced: Each motor is dynamically balanced to minimize vibrations, resulting in stable and smooth flight performance.
Specifications:
Model: XING2 2207
KV Options: 1855KV, 2755KV (selectable)
Version: CW Screw Thread
Input Voltage: Compatible with 4S to 6S LiPo batteries
Configuration: 12N14P
Stator Diameter: 22mm
Stator Length: 7mm
Weight: 31.6g (with short wire)
Wire Length: 20AWG, 160mm
Mounting Pattern: 16x16mm
Model: XING2 2306
KV Options: 1755KV, 2555KV (selectable)
Version: CW Screw Thread
Input Voltage: Compatible with 4S to 6S LiPo batteries
Configuration: 12N14P
Stator Diameter: 23mm
Stator Length: 6mm
Weight: 31.6g (with short wire)
Wire Length: 20AWG, 160mm
Mounting Pattern: 16x16mm
Applications:
For Vehicle Type: Airplanes, helicopters, and other RC models
Use: Ideal for vehicles and remote control toys
Upgrade Parts/Accessories: Suitable for upgrading to high-performance brushless motors
Package Includes:
1x iFlight XING2 Brushless Motor (select KV model)
4x M3x6 Screws
1x M5 Flanged Nylon Insert Lock Nut
Note: Propeller is not included.
The iFlight XING2 motors represent a significant upgrade in performance and durability, making them an excellent choice for enhancing your RC flying experience.
