M10Q-120 GPS Module

M10Q-120 is based on the UBLOX M10 chip, featuring fast and precise positioning. The same great performance as the M10Q-180 in a smaller package.

Specifications

• Chip: M10(10th Generation Chip)
• Frequency: GPS L1GLONASS L1BDS B1GALILEO ESBAS L1QZSS L1
• Input Voltage: 5V
• Antenna: Ceramic
• Channels: 72
• Battery: Built-in
• Compass: QMC5883
• Compass Orientation: Plug facing direction of flight and obviously antenna up, BF: CW 180 Flip
• Baud Rate: 115200bps
• Protocol: Dual NMEA/UBLOX
• Output Frequency: 1Hz-10Hz,10Hz default
• Speed Accuracy: 0.05m/s
• Horizontal Positioning Accuracy: 2D ACC1.5m(outdoor)
• Receiver Sensitivit:y Trace -166dBm; Capture -160dBm
• Dynamic Characteristics Height: 50000m; Speed 500m/s; Acceleration 4G
• Operating Temperature: -40C-+85C
• Storage temperature: -40C-+105C
• Weight: 2.7g
• Size: 12.5*17*5mm
