NE555 6V Delay Timer

NE555 Delay Timer

The NE555 delay timer switch is manufactured for high-performance timing and based on the NE555 chip. This delay switch moduleis a monostable switch module that finds itself very useful in vehicle-based applications likedelay to prevent car ignition. The NE555 delay timer switch module is constructed with a power indicator LED and switch trigger timing indication LED.

This is a monostable generator based on the NE555 integrated circuit. It has an adjustable delay time from 0 to 10 seconds using the potentiometer or by changing the capacitance. It is also capable of controlling the device below 220V/10A.

Applications:

• Tone generation.
• Alarm circuit.
• Frequency division applications.
• Relaxation oscillator.
• Digital counter circuits.
