Adavntage
H401 Hexacopter drone chassis is carbon fiber unibody molding, the overall quality of light, high strength, high toughness, high temperature resistance, good rainproof, high flight stability!
Performance Parameters
|
Fuselage Material |
Toray 3K Carbon Fiber |
|
Manufacturing Process |
High temperature and high pressure molding |
|
Thickness |
Regular 0.6mm |
|
Weight of casing |
1.5KG |
|
Weight of housing + power unit |
4.5KG |
|
Wheelbase |
1000mm |
|
Expansion Dimension |
1120mm*810mm*470mm |
|
Wheelbase |
1200mm |
|
Unfolded Dimensions |
1320mm*1200mm*470mm |
|
Folded Dimensions |
460mm*420mm*470mm |
|
Battery compartment |
205mm*135mm*90mm |
|
Recommended load |
3-5KG |
|
Unloaded Endurance |
70min |
|
Load capacity 3KG |
60min |
|
Whole machine without mounting weight (Red Dot 6s 27000*2 pieces)
|
9KG |
|
Control Distance
|
30KM (handheld ground station control), optional 4G/5G satellite communication unlimited distance |
Suitable for mounting
About Purchase
You are free to choose buy the following drone components according to your needs:
Optional 1: Drone Frame Type: H401-F
Optional 2: Drone Frame with Propulsion System Type: H401-P (Including airframe,motor, ESC, propeller blade)
Optional 3: Drone with Ready To Fly . Type: VF20E-R
