Want to experience the efficiency, long range and low latency of the ELRS protocol without purchasing a new radio? RadioMaster has you covered!
Featuring F-1000Hz refresh rates and a high-efficiency cooling system, the Ranger Micro 2.4GHz ELRS Module represents the cutting edge in ELRS technology. Attach the module to a compatible radio (TX16S,TX16S MkII, TX12,TX12 MkIIand more) to enjoy all that ELRS has to offer.
The included T-shape antenna is designed for maximum signal coverage. An optional MOXON antenna is available for directional applications.
*Note: The Ranger Micro 2.4GHz ELRS Module fits JR style micro module bays, for Nano connectors, please consider theRangerand theRanger Nano modules. For more information on the Ranger series, please checkhere.
Features
- Built-in ExpressLRS Backpack
- High-efficiencycoolingsystem
- WifiandBluetoothsupport
- Packetratesupto F-1000Hz
- T-antenna included
- WiththeMicroconnector,supportTX16SMKIIandTX12MKII radio
Specification
- Item:RangerMicroModule
- RegulatoryDomain:ISM2400
- MCU:ESP32(main),ESP8285(aux,asESP backpack)
- RFchip:SX1281IMLTRT
- FrequencyRange:2400MHz- 2480MHz
- Maximumpacketrate:500Hz/F-1000Hz (F-1000Hz mode requires EgdeTX 2.7.1 or later)
- Minimumreceiverrefreshrate:25Hz
- WifiSupport:Yes
- Bluetoothsupport:Yes
- XT30Powersupplyvoltage:DC6V-16.8V
- Weight:50g(withantenna)/40.5g(withoutantenna)
- Dimension:136*49*33mm(withTantenna)/74*49*33mm(withoutantenna)
Size
How to Replace Ranger Micro Board
Download
- Ranger Mirco User Manual
Package Includes
- 1*RangerMicroModule
- 1*TAntenna
