RadioMaster TX16S MKII MAX ELRS SPECIFICATIONS

Use: Vehicles & Remote Control Toys

Recommend Age: 12+y

Origin: Mainland China

Material: Composite Material

Special JB edition in the Carbon and Purple JB color scheme with JB

sound pack pre-installed and V4.0 Hall Gimbals. Comes with internal

ExpressLRS module.

SPECS

Size: 287129184mmWeight: 750g (without battery)Transmission frequency: 2.400GHz-2.480GHzTransmitter module:Option 1: Internal 4-in-1 multi-protocol module(CC2500 CYRF6936 A7105 NRF2401)Option 2: Internal ELRS(Sx1280)Transmitting power:lnternal 4-in-1 multi-protocol module : Max 100mw(protocol dependent)lnternal ELRS : Max 250mw(transmitting power is adjustable)Antenna gain: 2db (transmit power adjustable)Working current: 400mAWorking voltage: 6.6-8.4v DCRemote control distance:> 2km @ 22dbmRadio firmware: EdgeTXModule Firmware: Multiprotocol- Module (4IN1)-OR-ExpressLRS(ELRS)Channels:
Up to 16 channels (depending on the receiver)Display: 4.3-inch TFT
full-colour touch display with a resolution of 480 * 272Gimbal:Option 1: v4.0 Hall sensor with Aluminium fascia.Option 2: AG01 CNC Hall sensorModule Bay: JR compatible module bayUpgrade method: Supports USB-C online / SD card offline upgradeIMPROVEMENTS

• Improved internal circuity and optimized power supply.
• New charge circuitry with integrated reverse-polarity protection.
• Optimized charge lC. better balancing and USB-C charge current management.
• Rear mounted audio jack provides headphone output.
• V4.0 Gimbal improved centring and temperature stability(Same circuitry as AG01).
• Optional high/low rear grips included for improved ergonomics.
• Improved S1/S2 knobs with clear centre-detents.
• Improved LS/RS Sliders with smoother feel and better centre-detents.
• Redesigned battery cover for improved battery access.
• Retooled body shell with improved fit and finish.
• Trainer socket changed to standard TRS 3.5mm socket.
• Rear DIY Socket added for personalised mods.
• Improved internal plastics for better longevity.
• Available ELRS and 4in1 versions.

MAX units feature carbon look face plates and CNC finishing components and buttons.
