Overview
Raspberry Pi 5 8GB Development Computer features a 2.4GHz 64-bit quad-core Arm Cortex-A76 processor and an 800MHz VideoCore VII GPU for strong general compute and graphics acceleration. It adds advanced camera/display interfaces, versatile wired and wireless connectivity, and enhanced peripherals, suitable for multimedia, gaming, education, prototyping, and industrial tasks.
Key Features
- Flagship compute and graphics: 64-bit quad-core Arm Cortex-A76 at 2.4GHz paired with an 800MHz VideoCore VII GPU.
- Significant graphics capability: Supports OpenGL ES 3.1 and Vulkan 1.2; dual 4Kp60 display output with HDR; 4Kp60 HEVC decode.
- State-of-the-art camera/display support: Dual dedicated 4-lane 1Gbps MIPI DSI/CSI connectors, tripling total bandwidth, supporting any combination of up to two cameras or displays.
- Versatile connectivity: Gigabit Ethernet and PCIe interface, plus dual-band 802.11ac WiFi and Bluetooth 5.0/BLE.
- Enhanced peripherals: microSD card slot with high-speed SDR104 mode, 2 USB 3.0 (simultaneous 5Gbps), 2 USB 2.0, on-board On/Off power button, RTC, and Raspberry Pi standard 40pin header.
Ready to scale beyond prototypes? Check reComputer AI Series: 26 TOPS of raw AI performance empowered by Hailo, leveraging RPi 5 era architecture, professional-grade performance, prototype-friendly price, and plugandplay simplicity.
Specifications
| CPU | 2.4GHz quad-core 64-bit Arm Cortex-A76 CPU, with cryptography extensions, 512KB per-core L2 caches, and a 2MB shared L3 cache |
| GPU | VideoCore VII GPU, supporting OpenGL ES 3.1, Vulkan 1.2 |
| Display Output | Dual 4Kp60 HDMI display output with HDR support |
| Video Decoder | 4Kp60 HEVC decoder |
| RAM | 8GB LPDDR4X-4267 SDRAM |
| WiFi | Dual-band 802.11ac WiFi |
| Bluetooth | Bluetooth 5.0 / Bluetooth Low Energy (BLE) |
| Storage | microSD card slot, with support for high-speed SDR104 mode |
| Power Button | On/Off included |
| USB Ports | 2 USB 3.0 ports, supporting simultaneous 5Gbps operation; 2 USB 2.0 ports |
| Ethernet | Gigabit Ethernet, with PoE+ support (requires separate PoE+ HAT) |
| Camera/Display | 2 4-lane MIPI camera/display transceivers |
| PCIe Interface | PCIe 2.0 x1 interface for fast peripherals (requires separate M.2 HAT or other adapter) |
| Power | 5V/5A DC power via USBC, with Power Delivery support |
| Raspberry Pi Header | Raspberry Pi standard 40pin header |
| Real-time Clock (RTC) | Powered from external battery |
Applications
Raspberry Pi 5 Smart Home Hub
Home Assistant is a free and open-source smart home hub that centralizes home automation and runs locally for privacy and reliability. It can be extended with Home Assistant Cloud for encrypted remote control via voice assistants.
The installation method is smooth, direct and simple.
- PC alternatives
- Multimedia Center
- Console
- Education and Learning Tools
- Smart Home Systems
- Sensor Network
- Remote Monitoring
- Industrial Automation
- Embedded Systems Development
Documents
- Raspberry Pi 5 product brief
- Raspberry Pi 5 mechanical drawing
- Getting started documentation
- RP1 peripherals documentation
ECCN/HTS
| HSCODE | 8471504090 |
| USHSCODE | 8517180050 |
| UPC | |
| EUHSCODE | 8471800000 |
| COO | UNITED KINGDOM |
Whats Included
- Raspberry Pi 5 8GB 1
