RODE NT6 Compact Condenser Microphone

RODE NT6 Compact Condenser Microphone

Rode SKU: NT6 | Helix SKU: RMNT6

Overview

Compact 1/2″ condenser microphone with 3m (10′) Kevlar reinforced cable to detachable capsule head. Also features HPF and PAD.

• 1/2 condenser capsule with remote preamp
• Gold sputtered externally biased condenser
• Two position PAD – 0dB and -10dB
• Two position High Pass Filter – flat and 80Hz
• Includes two-axis swivel mount, 3m Kevlar fibre reinforced cable, windshield and zip pouch
• Heavy duty satin-nickel plated body
• Low noise and full frequency response
• Designed and manufactured in Australia
• 10 year extended warranty when youregister your microphone

The RDE NT6 is an extremely compact 1/2″ cardioid condenser microphone, specifically designed for difficult mounting applications where the highest quality audio is required.

Although clearly relevant to instrument miking, the NT6 is extremely well suited to any situation where an unobtrusive but powerful microphone is required such as location recording.

The microphone is split into two modular components, joined by via a custom 3m (10′) shielded, Kevlar reinforced cable.

Featuring a gold-sputtered, true-condenser capsule, the NT6 capsule head measures 45mm (1.8) in length and weighs only 42gm (1.5oz). The included all-metal, multi-position mounting ring provides 180 degrees of vertical rotation.

The NT6 preamp-body incorporates both a high-pass filter and pad setting. The high-pass filter can be introduced to cut vibration, rumble and undesired sounds sources under 80Hz, while the PAD offers a -10dB level attenuation, useful when recording louder sound sources.

The NT6’s small form factor make it an ideal small diaphragm cardioid microphone for use in the Mid-Side (M/S) stereo array, in combination with a figure-8 largediaphragm microphone such as the NT2-A, NT2000 or K2.

The NT6 is designed and made in Australia, and covered by RDE’s industry leading 10 year warranty.

Specifications

Acoustic Principle	Pressure Gradient
Active Electronics	JFET impedance converter with bipolar output buffer
Capsule	0.50″
Polar Pattern
Address Type	End
Frequency Range	40Hz – 20kHz
Output Impedance	200
Maximum SPL	135dB SPL (@ 1kHz, 1% THD into 1K load)
Maximum Output Level	6.0mV
Sensitivity	-37.0dB re 1 Volt/Pascal (16.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
Equivalent Noise Level (A-weighted)	19dB-A
Power Options
Weight	386.00gm
Dimensions	189.00mmH x 64.00mmW x 20.00mmD
Output
Warranty	1 year with free extension to 10 years following registration
