kv250:
| X5212S KV230 | |||||||
| Specifications | X52125 | ||||||
| Stator Diameter | 52mm | ||||||
| Stator Thickness | 12mm | ||||||
| No.of Stator Slots | 24 | ||||||
| No.of Rotor Poles | 28 | ||||||
| Motor Kv | 230 | KV | |||||
| NO-Load Current(A/10V) | 0.8A | ||||||
| Motor Resistance | 56m | ||||||
| Max Continuous Current | 45A/30s | ||||||
| Max Continuous Power | 2160W | ||||||
| Weight | 234g | ||||||
| Rotor Diameter | 59mm | ||||||
| Body Length | 35mn | ||||||
| Max Lipo Cel | 12S | ||||||
| ESC | 80A | ||||||
| Reconmend Prop(inch) | EOLO 15*5.516*6 | ||||||
| () | (V) | (A) | (g) | (W) | (g/W) | (rpn | |
| EOL015*5 .5 |
44.4 | 3 | 1000 | 133.2 | 7.51 | 4268 | |
| 3.9 | 1250 | 173.16 | 7.22 | 4739 | |||
| 4.9 | 1500 | 217.56 | 6.89 | 5205 | |||
| 5.9 | 1750 | 261.96 | 6.68 | 5600 | |||
| 7 | 2000 | 310.8 | 6.44 | 5979 | |||
| 9.5 | 2500 | 421.8 | 5.93 | 6623 | |||
| 12.1 | 3000 | 537.24 | 5.58 | 7250 | |||
| 15.1 | 3500 | 670.44 | 5.22 | 7773 | |||
| 18.3 | 4000 | 812.52 | 4.92 | 8313 | |||
| 25.5 | 5050 | 1132.2 | 4.46 | 9182 | |||
| 48 | 2.9 | 1000 | 139.20 | 7.18 | 4254 | ||
| 3.7 | 1250 | 177.60 | 7.04 | 4773 | |||
| 4.6 | 1500 | 220.80 | 6.79 | 5209 | |||
| 5.5 | 1750 | 264.00 | 6.63 | 5598 | |||
| 6.5 | 2000 | 312.00 | 6.41 | 5948 | |||
| 8.9 | 2500 | 427.20 | 5.85 | 6643 | |||
| 11.4 | 3000 | 547.20 | 5.48 | 7238 | |||
| 14.1 | 3500 | 676.80 | 5.17 | 7778 | |||
| 16.9 | 4000 | 811.20 | 4.93 | 8298 | |||
| 24.1 | 5000 | 1156.80 | 4.32 | 9185 | |||
| 29.4 | 5800 | 1411.20 | 4.11 | 9776 | 3min 115 | ||
| EOL016*6 | 44.4 | 2.8 | 1000 | 124.32 | 8.04 | 3455 | |
| 3.6 | 1250 | 159.84 | 7.82 | 3832 | |||
| 4.6 | 1500 | 204.24 | 7.34 | 4160 | |||
| 5.5 | 1750 | 244.20 | 7.17 | 4481 | |||
| 6.6 | 2000 | 293.04 | 6.83 | 4772 | |||
| 8.9 | 2500 | 395.16 | 6.33 | 5334 | |||
| 11.6 | 3000 | 515.04 | 5.82 | 5825 | |||
| 14.5 | 3500 | 643.80 | 5.44 | 6317 | |||
| 17.5 | 4000 | 777.00 | 5.15 | 6724 | |||
| 24.4 | 5000 | 1083.36 | 4.62 | 7462 | |||
| 32.3 | 6000 | 1434.12 | 4.18 | 8667 | |||
| 38.3 | 6800 | 1700.52 | 4.00 | 8204 | |||
| 48 | 2.6 | 1000 | 124.80 | 8.01 | 3410 | ||
| 3.4 | 1250 | 163.20 | 7.66 | 3803 | |||
| 4.2 | 1500 | 201.60 | 7.44 | 4139 | |||
| 5.2 | 1750 | 249.60 | 7.01 | 4478 | |||
| 6.2 | 2000 | 297.60 | 6.72 | 4773 | |||
| 8.3 | 2500 | 398.40 | 6.28 | 5370 | |||
| 10.8 | 3000 | 518.40 | 5.79 | 5819 | |||
| 13.6 | 3500 | 652.80 | 5.36 | 6264 | |||
| 16.1 | 4000 | 772.80 | 5.18 | 6715 | |||
| 22.8 | 5000 | 1094.40 | 4.57 | 7463 | |||
| 29.9 | 6000 | 1435.20 | 4.18 | 8204 | |||
| 44.1 | 7660 | 2116.80 | 3.62 |
