Overview
The T-Motor A10L is a Modular Propulsion System configured as A10L (Motor) + 14S FOC 200A (ESC) + MF3628P (Propellers) for 20L quadcopter or 30L hexacopter agricultural drones. Recommended load capacity (liquid): 20L for agriculture quadcopter drone, 30L for agriculture hexacopter drone. Recommended take-off weight: 44~52kg (quadcopter) and 66~78kg (hexacopter).
Key Features
- Complete matched setup: A10L motor + 14S FOC 200A ESC + MF3628P propellers
- Recommended battery: 12~14S (LiPo)
- Ingress protection: IPX6
- Silicone protective cover with two colors optional: Fluorescent Orange / Industrial Gray
- ESC control method: PWM/CAN; protocols: DRONE CAN, UAV CAN, CUBE CAN
- Wiring: Power Wires 12#AWG Red & Black; Signal Wires 5P Teflon
Specifications
| Model No. | A10L KV110 |
| Tube Size | 40mm |
| Setup | A10L (Motor) + 14S FOC 200A (ESC) + MF3628P (Propellers) |
| Recommended Battery | 12~14S (LiPo) |
| Wire Material, Wire Gauge, Color | Power Wires: 12#AWG Red & Black; Signal Wires: 5P Teflon |
| Wire Length | 98010mm |
| Rated Thrust | 11~13kg |
| Efficiency at Rated Thrust | 7.3g/W (13kg) |
| Max Thrust | 26kg |
| Weight | 18702%g (Incl. Wires + Prop) |
| IP Rating | IPX6 |
| Recommended Ambient Temperature | -30~50 |
Motor Specs
| Stator Size | 99*19mm |
| KV | 110 |
ESC Specs
| Throttle Range | 1100~1940us (Fixed) |
| Max Voltage | 61V |
| Protocol | DRONE CAN, UAV CAN, CUBE CAN |
| Peak Current (For A Short Time) | 200A (Open environment and temperature <= 60) |
| Control Method | PWM/CAN |
| BEC | NO |
Prop Specs
| Model No. | MF3628P (Polymer Folding) |
| Length | 36 Inch (914mm) |
For compatibility checks, configuration support, or bulk purchasing, contact [email protected] or visit https://rcdrone.top/.
Whats Included
- A10L Modular Propulsion System 1 (Excl. Carbon Tube)
- Parts Bag 1
Applications
- 20L agriculture quadcopter drones
- 30L agriculture hexacopter drones
Details
The T-Motor brushless motor comes pre-fitted with a two-blade propeller for straightforward installation on multirotor builds.
T-Motor hardware features a black cylindrical motor mounted in a bright orange housing with a round front cover for a tidy, protected setup.
Detailed dimensions help confirm hub size and blade spacing for proper fitment and clearance.
The thrust performance curves plot torque, RPM, current, efficiency, and power across the operating range to help with prop and load selection.
The T-Motor A10L modular propulsion system includes the motor-and-prop module plus a parts bag with mounting plate and fasteners (carbon tube not included).
