Overview
The Tattu NEO series smart battery is designed for UAV applications such as inspection, surveying, firefighting, logistics, and other professional uses. It supports a 1C charging rate, 4.45V ultra high voltage, MOSFET protection, and real-time battery data reading via a Bluetooth app.
Key Features
- Customized structure: Side rails and a bottom female connector for direct plug-and-play operation.
- MOSFET protection: Helps prevent short-circuit risks.
- Communication support: Multi-battery serial and parallel communication.
- Ultra High Voltage (UHV): Rated up to 4.45V.
- Bluetooth app support: Real-time battery data reading.
Specifications
| Brand | TATTU |
| Series | Tattu NEO |
| Model | TANE30K12S5HVX |
| Capacity | 30000mAh |
| Nominal Voltage | 47.4V (Cell: 3.95V) |
| Configuration | 12S1P |
| Discharge Rate | 5C |
| Charging Rate | 1C |
| Dimensions (Max, TWL) | 99.5 x 206 x 263.5mm |
| Length (5mm) | 263.5mm |
| Width (2mm) | 206mm |
| Height (2mm) | 99.5mm |
| Weight | Approx. 5950 100g |
| Connector | PDC1810F0002 / Prolanv Side Connector |
| Paired Charger | TA3200 series / TA7200PRO |
Applications
- UAV inspection
- Surveying
- Firefighting
- Logistics
