TBS CROSSFIRE SIXTY9

What could be better than the best Crossfire receiver and an improved Unify Pro32 video transmitter making sweet love? Exactly! Nothing, nothing at all.

Introducing the TBS Crossfire Sixty9, a VTx and RC receiver AIO board sporting a race-friendly, long-range capable video transmitter combined with the same on the TBS Crossfire side. Mounting holes are 20×20.

Outputs 2x CRSF + 2x PWM (or 6x PWM) directly to your FC. The main JST-SH connector connects to your flight controller and video camera (or also FC for those that like the FC-OSD).

Features:

• Integrated video transmitter control with long range and (team-)race functions
• Dedicated low-noise power supply for receiver and video transmitter
• Sleek 20×20 mounting form factor
• Plug&play connection and solder pads connectivity
• High power analog adjustable video transmitter (up to 1W with perfect cooling)

Specifications

• CRSF V3 ready
• Weight 4.1g (board only)
• Antenna ports 1x video transmitter, 1x R/C receiver
• Size 24mm x 24mm
• Input voltage 5V
• Requires Firmware V4.62 and above
• VTX Table VTX Table for Betaflight

Includes

• 1x TBS Crossfire Sixty9
• 1x Locking TBS Crossfire Immortal-T antenna
• 1x Locking u.FL to SMA mount (for VTx)
• 1x JST-SH x 9 connector
• 4x M3 rubber dampers

Downloads

• TBS Crossfire – RED Declaration of Conformity
• TBS Crossfire Manual
