Truerc X-AIR “X” 5.8 MK II Quad Set For DJI FPV [EOL]

The X antennas set is a cross-polarized antennas kit meant to be used with DJI fpv goggles and airunit. This cross-polarized arrangement offer a more reliable link, maximize bit rate and minimize latency in cluttered environments, like indoor or between buildings. It consist of two RHCP and two LHCP stand-aloneX-AIRfor the goggles and one of each RHCP and LHCPOCPantennas for the airunit.

Installation

Place the X-AIRs on the goggles following a X pattern:

• Bottom left: LHCP
• Top left: RHCP
• Top right: LHCP
• Bottom right: RHCP

Specs

• Gain (X-AIR):9.5-10.5 dBic
• Gain (OCP):1.6 dBic
• Polarization:RHCP and LHCP
• Beam-width* (X-AIR):120deg
• Beam-width @-3dB** (X-AIR):68deg.

*Coverage where reception is at least equivalent to an omni.
**Coverage where at least 70% of the max range is obtained.

Includes

• 2x RHCP X-air 5.8 MK.II
• 2X LHCP X-air 5.8 MK.II
• 4X 45deg low-loss RP-SMA adapters
• 1x RHCP OCP with MMCX90 connector
• 1x LHCP OCP with MMCX90 connector

Useful print!

• X tie brace

FAQ

Can I use something other than the OCP with MMCX90 connector on the airunit?

-Yes, if you have pigtails you can use antennas with SMA. Leave a comment while ordering and we can swap for the connector type you need.

Can I use this with the vista unit?

-Yes, however the performances wouldnt be as good as they could be with an airunit.
