Overview
The VCI SPARK 2004 3000KV Brushless Motor is a high-performance power unit designed for 3.5-inch cinematic drones, freestyle quads, and racing builds. Engineered for 3S4S LiPo batteries, it offers explosive thrust, smooth control, and a durable structure, making it ideal for compact cinewhoops or lightweight racing drones.
With a powerful 375.7W max output, precise N52SH arc magnets, and a lightweight 16.5g build, the SPARK 2004-3000KV strikes the perfect balance between performance and efficiency for high-throttle applications.
Key Features
-
Designed for 3.5″ Cinematic FPV Builds
Ideal for cinewhoop drones that require high thrust in tight form factors. -
High Performance on 4S
Capable of delivering up to 768g thrust with 23.48A peak current, making it suitable for aggressive freestyle and cinematic shots. -
Precision Construction
-
N52SH arc magnets
-
12S14P stator configuration
-
Lightweight 16.5g (with wire)
-
-
Thermal and Efficiency Optimization
-
Peak operating temperature only 71C at 100% throttle
-
Maximum efficiency: 3.07g/W (at 30% throttle)
-
Technical Specifications
| Parameter | Value |
|---|---|
| Model | SPARK 2004-3000KV |
| KV | 3000KV |
| Rated Voltage | 4S (16V) |
| Peak Current | 23.48A |
| Max Power | 375.7W |
| Shaft Diameter | 1.5mm |
| Shaft Length | 3.5mm |
| Configuration | 12S14P |
| Internal Resistance | 110m |
| Idle Current (10V) | 0.7A |
| Dimensions | 24.6 L17.7mm |
| Magnet Type | N52SH Arc |
| Wire Spec | 24AWG 100mm |
| Weight | 16.5g (including wires) |
Performance Data with GF D90-3 Propeller @ 4S
| Throttle | Current (A) | Thrust (g) | Power (W) | Efficiency (g/W) | RPM |
|---|---|---|---|---|---|
| 30% | 3.30 | 162 | 52.77 | 3.07 | 17703 |
| 50% | 6.98 | 309 | 111.68 | 2.77 | 23460 |
| 70% | 12.76 | 484 | 204.20 | 2.37 | 29539 |
| 100% | 23.48 | 768 | 375.70 | 2.04 | 38400+ |
Application
-
3.5 Inch Cinewhoop Drones
-
FPV Freestyle Racing Quads
-
Lightweight Long-range Builds
Why Choose SPARK 2004 3000KV?
-
Precision-built for cinematic and agile flying
-
Excellent thrust-to-weight ratio
-
Smooth throttle response
-
Optimized for heat dissipation and durability
SPARK 2004 motor series specs: KV ratings 1850, 2150, 3000; voltage 6S-16V; current up to 23.48A; max power 426.96W, 427.2W, 375.7W; efficiency peaks at 3.85g/W, 3.5g/W, 3.0g/W respectively.
