Technical Specifications
- Model: XH-W3001
- Operating Voltage: DC 12V
- Power Rating: Max 120W
- Temperature Measurement Range: -50C to +110C
- Control Accuracy: 0.1C
- Display Type: LED Digital Display (Red)
- Output Type: Relay Output
- Relay Capacity: 10A (Max Load 120W at 12V)
- Sensor Type: Waterproof NTC 10K Temperature Probe
- Temperature Setting Range: -50C to +110C
- Working Mode:
- Heating Mode (increase temperature)
- Cooling Mode (reduce temperature)
- Wiring:
- Input: 12V DC
- Output: Normally Open/Closed relay terminals
- Features:
- Over-temperature protection
- High precision temperature control
- User-defined temperature threshold
- Easy 3-button interface
- Applications:
- Incubators
- Aquariums
- Water heaters
- Greenhouses
- HVAC systems
- DIY temperature control projects
Technical Description
The XH-W3001 DC 12V 120W Digital Thermostat Switch is a high-precision temperature controller designed for a wide range of heating and cooling applications. Equipped with a bright LED display and a waterproof NTC temperature sensor, this thermostat ensures accurate real-time monitoring and control from -50C to +110C.
The module features a relay-based switching output capable of handling up to 120W, making it ideal for incubators, aquariums, water heaters, greenhouse climate systems, and DIY automation projects. With simple 3-button programming, you can easily set upper and lower temperature limits, choose heating or cooling mode, and protect devices from over-temperature damage.
Reliable, compact, and easy to use, the XH-W3001 is a must-have thermostat module for electronics projects and temperature-controlled systems.
