Overview
OneVDLink R30 is an integrated video + flight-controller data networking link designed for UAV applications. It uses dual-band 1.4GHz + 2.4GHz communication with dynamic frequency hopping to improve link robustness in interference-heavy environments. In point-to-point mode it supports 30Mbps throughput, <25ms one-way air latency (UL/DL), and a 30km+ communication distance (tested in specific scenarios). It also supports a star-mesh network up to 32 nodes for scalable relay/expansion deployments.
Notes: 30km+ is stated as laboratory/specific-scenario test data; real-world range depends on environment, antenna placement, regulations, and interference.
Key Features
-
Dual-band 1.4GHz / 2.4GHz coordination with dynamic frequency hopping
-
30Mbps communication bandwidth
-
<25ms one-way air latency (UL and DL)
-
30km+ point-to-point distance (scenario/lab referenced)
-
Star mesh networking up to 32 nodes, expandable relay communication
-
Wide voltage input: 1026V DC, easy integration on different platforms
-
Adaptive transmit power control: 25mW 300mW (auto-adjust to reduce power draw at short range)
-
Built-in active cooling (internal fan) for long-duration high-performance operation
-
Web configuration via browser login (Edge recommended)
Interfaces & I/O
OneVDLink R30 integrates common UAV/robot interfaces for quick system integration:
-
Type-C
-
SBUS
-
DC IN (1026V)
-
SBUS OUT
-
UART1 / UART2
-
Ethernet (ETH)
Specifications (from provided images)
RF & Link
| Item | Specification |
|---|---|
| Frequency bands | 24002483.5 MHz; 1427.91447.9 MHz |
| Bandwidth (throughput) | 30Mbps |
| Anti-interference | Dynamic frequency hopping |
| TX power level | 2.4G: 25dBm 2; 1.4G: 25dBm 2 (optional) |
| Point-to-point distance | 30km+ (scenario/lab referenced) |
| Network nodes | Max 32 |
| Encryption | ZUC / SNOW3G / AES (selectable) |
| Modulation | QPSK / 16QAM / 64QAM |
| One-way air latency | UL <25ms; DL <25ms |
Receiver Sensitivity (BLER 3%)
| Band | Channel / Rate | Sensitivity |
|---|---|---|
| 2.4G (24415 freq) | 20MHz, 10Mbps | -92 dBm |
| 2.4G (24415 freq) | 20MHz, 5Mbps | -96 dBm |
| 2.4G (24415 freq) | 10MHz, 10Mbps | -89 dBm |
| 2.4G (24415 freq) | 10MHz, 5Mbps | -92 dBm |
| 1.4G (14379 freq) | 20MHz, 20Mbps | -86 dBm |
| 1.4G (14379 freq) | 20MHz, 5Mbps | -97 dBm |
| 1.4G (14379 freq) | 10MHz, 10Mbps | -88 dBm |
| 1.4G (14379 freq) | 10MHz, 5Mbps | -94 dBm |
Power, Mechanical & Environment
| Item | Specification |
|---|---|
| Input voltage | 1026V DC |
| Power consumption | <6W (whole unit, working) |
| Cooling | Built-in active cooling |
| Operating temperature | -20C to 75C |
| Dimensions | 91 61.2 18 mm |
| Weight | 132 g |
| Web configuration | Browser login configuration (Edge recommended) |
| Interface detail (spec list) | DC IN1, SBUS IN1, UART2, ETH1 |
Whats in the Box
OneVDLink R30 Air Unit Package List (as shown)
-
OneVDLink R30 Air Unit
-
1.4G/2.4G dual-band antennas 2
-
XT30 power cable
-
Antenna pigtail cables 50cm 2
-
Serial cable 2
-
VDLink SBUS cable
-
SBUS OUT cable
-
Ethernet cable
-
Type-C cable
-
Certificate ()
OneVDLink R30 Ground Unit Package List (as shown)
-
OneVDLink R30 Ground Unit
-
1.4G/2.4G dual-band antennas 2
-
XT30FXT60M power cable
-
Antenna pigtail cables 50cm 2
-
Serial cable 2
-
VDLink SBUS cable
-
SBUS OUT cable
-
Ethernet cable
-
Type-C cable
Typical Applications
-
UAV flight controller telemetry + video integrated link
-
Long-range point-to-point data/video backhaul
-
Multi-node (up to 32) star-mesh relay and expanded coverage deployments
-
UAV/robot systems requiring SBUS / UART / Ethernet connectivity with wide-voltage power input
Details
OneVDLink R30 devices with dual antennas, featuring ventilation design and labeled ports. Text highlights integrated graph and data networking capabilities.
Smart dual-band 1.4/2.4GHz intelligently avoids interference, ensuring stable, clean data transmission in complex electromagnetic environments.
ZeroOne OneVDLink R30 enables 30km range, 30Mbps bandwidth, <25ms latency. Transmits uncompressed 1080P/2K video smoothly. Ideal for real-time remote monitoring with zero lag or artifacts.
OneVDLink R30 supports star network with 32 nodes, expandable relay communication. Features wide voltage input 10-26V for flexible deployment and integration.
Advanced cooling ensures stable high performance. Smart power control adjusts transmission from 25mW to 300mW, optimizing signal quality and reducing energy use during close-range communication.
ZeroOne OneVDLink R30 offers versatile connectivity: Type-C, SBUS, UART, Ethernet, power input. Designed for seamless integration with flight controllers and peripherals via multiple interface ports.
OneVDLink R30 supports 2.4G/1.4G bands, 30Mbps bandwidth, dynamic frequency hopping, AES/ZUC/SNOW3G encryption, QPSK/16QAM/64QAM modulation, <25ms latency, up to 32 nodes, web config via browser, <6W power, -20C~75C operation.
OneVDLink R30 includes sky and ground units with dual-band antennas, XT30/XT60M cables, 50cm antenna feed lines, serial cables, SBUS lines, Ethernet, Type-C cable, and certification card.
